TENKILOMETERS HG8245H SINGLE BAND XPON ONU ONT FTTH 4GE is high-quality. HG8245H FTTH is an optical network terminal (ONT), which is a high-end home gateway in the FTTH solution. By using GPON technology, ultra-broadband access is provided for home and SOHO users. Huawei HG8245H FTTH provides two POTS ports, four GE auto-adapting Ethernet ports, and one Wi-Fi port. Huawei HG8245H FTTH features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, this model provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.
|
Model |
HG8245H |
|
Pots |
4GE + 2POTS + 1WIFI + 1USB |
|
Working environment |
Operating temperature: 0ºC to 40ºC |
|
Environment humidity: 5% to 95% (noncondensing) |
|
|
Typical power consumption |
9 W |
|
Power specifications |
Power adapter input: 100 to 240 V AC, 50–60 Hz |
|
System power supply: 11–14 VDC, 2 A |
|
|
WLAN |
802.11b/g/n |
|
VoIP |
H.248 and SIP |
|
Support IPv4 or IPv6 |
IPv4 and IPv6 |
|
Encapsulation mode |
IPoE or PPPoE |
|
Support NAT |
Yes |
|
Security |
IP Filter MAC Filter URL Filter |
|
USB Port |
Used to connect to USB storage device |
|
Dimensions(L*W*H) |
176 mm x 138.5 mm x 28 mm |
|
Weight |
About 1 Kg |
· Smart interconnection
Smart Wi-Fi coverage
SIP/H.248 auto-negotiation
Any port any service
Parental control
L2/L3 (IPv4) forwarding: 1G uplink, 2G downlink
· Smart service
Smart Wi-Fi sharing:
Portal/802.1x authentication
SoftGRE-based sharing
Association of one account with two POTS ports
· Smart O&M
IPTV video quality diagnosis
Variable-length OMCI messages
Active/Passive rogue ONT detection and isolationCall emulation, and circuit test and loop-line testPPPoE/DHCP simulation testing
WL AN emulation
